Инкрементальный энкодер Kuebler Sendix 7100

The incremental encoders Sendix 7100 / 7120 in a compact 70 mm stainless steel housing have an ATEX/IECEx mining approval. These shock- and vibration-resistant encoders operate flexibly with a resolution of up to 5000 pulses per revolution and are available with axial and radial cable outlets. These encoders are ideally suited for potentially explosive areas in mines (above/ground underground).

Оставить заявку

Характеристики
Характеристики
Отзывы ⁰

Dimension	Ø 70 mm
Shaft type	10 mm shaft, with flat surface 12 mm shaft, with keyway
Flange type	Synchro flange / Servo flange Clamping flange Ø 70.00 mm
Working temperature	-40 °C … +60 °C
Protection level	IP67
Connection types	Axial cable Radial cable
Max. rotational speed	6.000 min-1
Weight	2800 g

teh
Ед	шт
Артикул	7100
dr
Колво	1
